Size | Pattern | PR | Tread Depth(mm) | (TT)(TL) TT/TL | RIM | Inflated dimenison | Inflation pressure (kpa) | Load Capacity(kg) | Application Machinery | |||
Section width (mm) | Overall diamter (mm) | 0KM | 5KM | 10KM | ||||||||
26.5-25 | E4 | 46 | 50 | TL | 22.00/3.0 | 675 | 1760 | 800 | / | / | 26000 | reach stacker,fork track |
24.00-29 | E4 | 42 | 36 | TL | 17.00/3.5 | 650 | 1975 | 900 | 48900 | 35300 | 32600 | reach stacker,fork track |
21.00-25 | E4 | 48 | 52 | TL | 15.00/3.0 | 575 | 1750 | 1100 | 40000 | 34000 | 30000 | RTG & reach stacker |
18.00-25 | E4 | 48 | 54 | TL | 13.00/2.5 | 495 | 1671 | 1100 | 34800 | 30000 | 27600 | RTG & reach stacker,fork track |
16.00-25 | E4 | 40 | 52 | TL | 11.25/2.0 | 430 | 1490 | 1075 | 26400 | 21300 | 19800 | reach stacker,fork track |
14.00-24 | E4 | 36 | 46 | TT/TL | 10 | 375 | 1370 | 1100 | 21600 | 17400 | 16200 | reach stacker,fork track,empty container transfer |
12.00-24 | E4 | 28 | 46 | TT/TL | 8.5 | 315 | 1245 | 950 | 14000 | 12000 | 9900 | empty container transfer and small fork track |
